Corrosion-Resistant PVDF Flanged Ball Valve

Corrosion-Resistant PVDF Flanged Ball Valve

Constructed from 100% virgin PVDF, this PVDF Flanged Ball Valve offers superior resistance to aggressive acids and alkalis. Its universal flange design (DIN/ANSI/JIS) ensures seamless compatibility with your industrial piping systems. Ideal for chemical processing and wastewater treatment applications.

 Main Structural Features

• Superior Corrosion Resistance:Molded from 100% PVDF, providing excellent resistance to strong acids, alkalis,solvents.
• Leak-Free Integrity:One-piece body design eliminates potential leak paths, ensuring safety in hazardous chemical handling.
• High Compatibility:Flange connections strictly follow DIN/ANSI/JIS standards for seamless installation.
• Low Torque Operation:Precision-machined ball and PTFE seat ensure smooth operation with minimal fluid resistance.

Industrial Applications

• Chemical Processing:Used for handling strong acids, alkalis, and solvents due to excellent chemical resistance.
• Water Treatment:Controls flow in dosing, filtration, and neutralization systems.
• Pharmaceutical & Food Industries:Ensures hygienic, contamination-free operation in high-purity processes.
• Semiconductor & Electronics:Handles ultrapure chemicals safely in sensitive manufacturing processes.

 FAQ for PVDF Flanged Ball Valve:

Q: What pressure can PVDF ball valves handle?
A:PVDF ball valves typically withstand pressures up to 16 bar (232 psi), making them suitable for industrial chemical and water systems.

Q: What temperature range is suitable for PVDF ball valves?
A:They can operate safely between -20°C to 140°C (-4°F to 284°F), allowing use in most chemical, pharmaceutical, and high-purity applications.
