Standard chemical slurry pump-Horizontal Plactic casing in back pull-out design centrifugal pump, designed by ISO2858 standard.
Order(MOQ) :
1Product Origin :
RISTERLead Time :
15 daysConnection :
FLANGE(DIN/ANSI/JIS)Pressure Rating :
PN16/Class 150/Class 300Size Range :
1.0" - 12" (DN25-DN300)Standard chemical slurry pump
Standard chemical slurry pump, offers excellent chemical resistance, stable hydraulic performance, and reliable standardized design. With optimized materials and cost-effective manufacturing, Delivers long service life, easy maintenance, and fast delivery, making it a competitive and dependable solution for chemical processing applications.
Q: What mechanical seal system is used in this pump?
A: The KJB pump is equipped with a PLAN 54 double mechanical seal, which can be connected to an external circulation water system for continuous flushing and cooling, ensuring stable and leak-free operation.
Q: What operating performance can this pump achieve?
A: The KJB pump is designed for industrial chemical duty, supporting flow rates up to 1,000 m³/h, differential pressure up to 25 bar, and continuous operation at temperatures up to 150°C, depending on materials and configuration.
Teflon-lined magnetic pump offers superior corrosion resistance and completely leak-free operation, making it ideal for safely handling aggressive and hazardous chemicals.
Details
Teflon-lined mechanical seal centrifugal pumps provide excellent corrosion resistance, reliable sealing performance, and stable hydraulic efficiency, making them ideal for safely transferring aggressive and corrosive chemicals in industrial applications.
Details
Standard chemical slurry pump-Horizontal Plactic casing in back pull-out design centrifugal pump, designed by ISO2858 standard.
Details
Stainless steel chemical centrifugal pumps offer high mechanical strength, excellent corrosion resistance, and stable hydraulic performance, making them suitable for handling solvents, acids, and high-temperature fluids in demanding industrial applications.
Details
Stainless steel magnetic pumps offer leak-free operation, high mechanical strength, and reliable corrosion resistance, making them ideal for safe and low-maintenance transfer of chemicals and solvents in industrial applications.
Details
Vertical chemical submersible pumps offer excellent corrosion resistance, compact vertical design, and stable continuous operation, making them ideal for transferring aggressive chemicals directly from tanks or pits with minimal footprint and maintenance.
